MAWL®-ER
MODULAR ADVANCED WEAPON LASER - EXTENDED RANGE
The MAWL®-ER (Extended Range) is a Class 3B multi-function laser illuminator/aiming device.
SKU
MAWL-ER
The MAWL®-ER (Extended Range) is a Class 3B multi-function laser illuminator/aiming device. It is a high powered variant of the MAWL®-DA with infrared illuminators intended to offer greater capability at distance or in environments with excessive ambient lighting conditions. The device is capable of emitting a visible green 520 nm pointer beam, 860 nm invisible infrared illumination beams, and an 852 nm IR point beam.
B.E. Meyers™, B.E. Meyers & Co.™, B.E. Meyers & Co., Inc.™, and MAWL® are all trademarks of B.E. Meyers & Co., Inc.
| Part Number | MAWL-ER |
|---|---|
| Azimuth & Elevation | 0.3 mrad per click |
| Beam Divergence | Pointer: 0.5 mrad. Illuminator: 2°, 10°, 60° |
| Dimensions | 5.5” L x 2.8” W x 1.83” H |
| Environmentally Sealed | Yes - Waterproof to 20M up to 2 HRS |
| ITAR-Controlled | Yes |
| Laser Class | 3B |
| Laser Type | Visible Green/NIR |
| Lumens | N/A |
| Max Laser Class | 3B |
| Maximum Output Power | 200 mW |
| Model Number | MAWL-ER |
| Operational Temp | -20°C to 50°C |
| Operational Temperature Range | -20°C to 50°C |
| Output Modes | OFF // VIS // IR - Short, Mid, Long |
| Output Power | 40 mW - 200 mW |
| Output Power Modes | OFF // VIS // IR - Short, Mid, Long |
| Power Source | 1 3V CR123A or 2 AA 1.5V Batteries |
| Restriction | Sales restricted to Federal, State and local government law enforcement agencies through a direct purchase order. |
| Storage Temperature Range | -40°C to 70°C |
| Wavelength | IR Illuminator: 860nm | IR Pointer: 852 nm. | Green Pointer: 520nm |
| Weight w/ Batteries | 11.1 oz |
| Weight w/o Batteries | 10.5 oz |
